RouteRunner T9 · Powered by KEENON

More trays.
One trip.

The RouteRunner T9 carries multi-tray loads along mapped indoor delivery routes, helping staff spend less time walking orders across the building. New to RevoRoute — coming very soon. From KEENON’s exclusive Minnesota cleaning-robot dealer — with the same local support across the full KEENON lineup.

Newest to the R³ Fleet
Ask About the T9
Will it fit?Start with your spaceSee the best uses, route limits, and setup needs.Check the fit →
RouteRunner T9 delivery robot
See the next stepPlan your demonstrationFind out what we check together and how local setup works.Explore the demo →
View lease pricing
RouteRunner T9 — Lease Schedule
24 mo$834/mo
36 mo$575/mo
48 mo$454/mo
60 mo$382/mo
Rates vary by credit approval & term. We'll confirm your exact number at your demo. On the 60-month term that is roughly $13 a day. Lease terms not a fit? We also offer outright purchase, custom payment plans, and 3-, 6-, or 9-month pilot programs — tell us your budget and we'll build something that works.
Ask About the T9
Proof

New to Minnesota. Proven Worldwide.

The T9 hasn't run a Minnesota floor yet — we can walk through the delivery workflow and route requirements with you. You'd be one of the first in Minnesota, backed by local sales, training, and support.

Right Robot

We match the model to your facility — never the other way around.

Right Route

We map and optimize your space so it runs right from day one.

Trained Staff

Your team learns the robot before we hand over the keys.

Local Support

Shakopee-based service. We answer the phone.

What It Does

Built to carry the whole rush

The T9 carries up to 88.2 lb across four trays, with a 22 lb limit per tray. It shares the T10’s nominal total load capacity and offers more capacity than the narrower T11. Choose between them using aisle width, tray size, runtime, and your delivery workflow.

🍽

Multi-Tray Capacity

A tall shelf stack that moves several orders per run.

💪

High-Load Runs

Four trays for larger multi-order delivery runs.

🗺

Route Optimization

Routes planned around your mapped floor and delivery stops.

🔋

Long Shifts

Runs full service stretches on a single charge.

How It Works

Map the route. Repeat the delivery.

We map delivery stops and check the route with your team. Staff load and unload orders, keep the route usable, and plan charging around the actual workload.

  • LiDAR + vision navigation
  • Obstacle avoidance in live, busy spaces
  • Routes learned once, repeated all day
  • Frees your staff to stay with guests
Where It Fits

Built for your floor

Best fit

  • Restaurants
  • Hotels
  • Banquet & event centers
  • Casinos
  • Senior living
  • Food halls

Rated for 88.2 lb across 4 trays, with 13–18 hours of published runtime. Actual endurance depends on payload, route, traffic, and settings.

Not the right fit when...

  • The venue needs the smallest possible footprint — the T11 is built for narrower aisles
  • Deliveries need locked or private compartments — that's the W3
  • The floor plan changes constantly (pop-up seating, frequent rearranging)
  • The required passage is narrower than 27.6 in
  • The expectation is zero staff involvement

Not sure? RevoRoute can test the route in your facility before you make a decision.

Specifications

T9 specifications

Checked against the KEENON T9 user manual; charging, total capacity, slope and tray-clearance options are supplemented by KEENON’s product specifications. Figures use US units. Runtime varies with payload, route and settings.

SpecificationUS / valueWhat it means for your building
Dimensions (W×D×H)19.69 × 20.75 × 49.84 inCheck the footprint and turning room along the route.
Weight138.9 lbPlan transport and floor loading for the configured robot.
Touchscreen11.6 in (1080p)Onboard controls for staff.
Trays4, removableCheck loaded height, item size and weight on the demo route.
Load capacity88.2 lb total · 22 lb per trayCheck loaded height, item size and weight on the demo route.
Tray interior (W×D)19.13 × 15.12 inCheck loaded height, item size and weight on the demo route.
Tray clearance (4-tray)7.68 in top · 6.65 in lower threeCheck loaded height, item size and weight on the demo route.
Tray clearance (3-tray)9.96 in top · 8.98 in lower twoCheck loaded height, item size and weight on the demo route.
Tray accessOpen from front and rearCheck loaded height, item size and weight on the demo route.
Min passage width27.6 inMeasure the narrowest part of the actual route.
Travel speed0.33–3.28 ft/s, adjustableWorking speed varies with traffic and settings.
Max slope5°Observe the operating conditions shown; test transitions onsite.
Battery life13–18 hoursConfirm the battery and charging setup supplied.
BatteryDC 48V 12Ah; service replacementConfirm the battery and charging setup supplied.
Charge timeAbout 4 hours, 15% to 100%Include recharge time in the operating schedule.
ChargingAuto-docking pile + manual rechargerConfirm the setup for your facility during the demo.
NavigationLaser positioning (label positioning for start point)Confirm the setup for your facility during the demo.
SensorsLiDAR, stereo vision, image module, collision sensor, IMUKeep sensors clean and confirm optional equipment.
NetworkWi-Fi 2.4 GHzConfirm the setup for your facility during the demo.
Service life20,000 hoursManufacturer rating; actual life depends on duty and maintenance.
Operating temperature32–104°F, 20–80% RHStay within the manufacturer’s environmental limits.
Storage temperature5–113°FStay within the manufacturer’s environmental limits.

Specifications above are from the KEENON DINERBOT T9 product manual. Coverage, runtime and throughput figures are estimates — what you actually get depends on your layout, floor surface, traffic, speed setting, and charging and staff loading/unloading time. We measure the real numbers on your floor during the demo.

The Demo

What happens during your on-site demo

Once local demo availability is confirmed, we bring the T9 to your facility, map a real route, and measure passage widths, tray-load fit, and elapsed shift runtime against your actual service pattern.

The purpose of the demonstration is to determine whether the T9 fits your facility — not to force the wrong robot into the wrong application.

Local Support

Trained and supported right here in Minnesota

Right Robot + Right Route + Staff Training + Local Support

1

Demo & Assessment

2

Delivery & Setup

3

Mapping & No-Go Zones

4

Staff Training

5

Remote Troubleshooting

6

Route & Settings Changes

7

Shakopee Parts & Service

Questions

Straight answers about the RouteRunner T9

How much does the RouteRunner T9 cost?
$382 a month on a 60-month lease — roughly $13 a day. Shorter terms run higher (24 months is $834 a month). Outright purchase, custom payment plans, and 3-, 6- or 9-month pilot programs are also available. Rates vary by credit approval; we confirm your exact number at the demo.
Can we see a delivery robot run in our dining room first?
Reserve a demo now and you're first on the list when the T9 lands in Minnesota. Until then we can show you the RouteRunner T10 on your floor — same KEENON platform, so you'll see how the mapping, routes and training work.
T9, T10 or Slim T11 — which one do we need?
All three run the same KEENON delivery platform. The T9 is rated by KEENON for 13–18 hours on a charge and carries the lowest lease of the three. The T10 adds a 23.8-inch display for menus and promos and is already running in Minnesota. The Slim T11 is the narrow-aisle version. We'll tell you which one fits at the demo.
Where does the T9 work best?
Restaurants, hotels, event venues and senior living — repeat trips from kitchen to table or station to station, on clear aisles and a consistent floor. The exact passage width it needs is in the spec table above.
Who installs, trains and services it?
We do — from our shop in Shakopee. The people who demo and install the robot are the people who train your staff and service it: mapping and no-go zones, staff training, remote troubleshooting, route and settings changes, and parts and service out of Shakopee. No third-party dispatch.

Interested in the RouteRunner T9?

Call us and we'll walk through fit, routes, and options for your facility.
